CheckLine PosiTector 6000-FNDS3 Coating Thickness Gage



Duplex Coating Model (Zinc + Paint), Separate Probe 0–60 mils, 0–1500 μm

PosiTector® 6000 FNDS3 Duplex Coating Thickness Gauge with Advanced Display, Measures Coatings on Ferrous and NON-Ferrous Metals up to 60 mils / 1500 Microns – FNDS3-E
SKU: 6000-FNDS3

$1,932.00 USD

5 disponibles

5 disponibles

Agregar a la cotización
19 People watching this product now!

Payment Methods:


The 6000 Series Coating Thickness Gauge is a precise and rugged, coating thickness gauges that use magnetic and eddy current principles to measure coating thickness on both ferrous and non-ferrous metals, accurately and quickly. No calibration adjustment is required for most applications.

The Positector’s 2.8″ impact-resistant color touchscreen features a redesigned keypad for quick menu navigation. An IP65-rated enclosure is watherproof, dustproof, and water-resistant. The probe has a wear resistant ruby probe tip, for long-lasting calibration.

USB, WiFi, and Bluetooth connectivity to PosiSoft PC, Mac, and Smartphone software . Conforms to ISO 2178/2360/2808, ISO 19840, ASTM B244/B499/D1186/D1400/D7091/E376/G12, BS3900-C5, SSPC-PA2, US Navy NAVSEA PPI 63101-000, US Navy NAVSEA 009-32, AS 2331.1.4, AS3894.3-B, and other standards.

  • 0.1 Unit Resolution
  • Supplied in custom fit carrying case
  • Conforms to ASTM D-2240
  • Optional Removable Stainless Steel Barrel for Medical and Food Applications
  • Minimum Sample Thickness-Type A = 6.00 mm (0.250″)
    Minimum Sample Thickness-Type M = 1.25 mm (0.050″)


  • Ready to measure—no calibration adjustment required for most applications
  • Enhanced one-handed menu navigation
  • Flashing display—ideal in a noisy environment
  • RESET feature instantly restores factory settings


  • Solvent, acid, oil, water and dust resistant – weatherproof
  • Wear-resistant probe tip
  • Shock-absorbing, protective rubber holster with belt clip
  • Two year warranty on gage body AND probe


  • Certificate of Calibration showing traceability to NIST or PTB included (Long Form)
  • Built-in temperature compensation ensures measurement accuracy
  • Hi-RES mode increases displayed resolution for use on applications that require greater precision
  • Conforms to national and international standards including ISO and ASTM


  • Fully interchangeable probes are compatible with ALL gage bodies
  • Multiple Calibration adjustment options including 1 point, 2 point, known thickness, average zero
  • Selectable display languages
  • Hi Contrast backlit display for bright or dark environments
  • Flip display enables right-side-up viewing
  • Extended cables available (up to 75 m/250 ft) for underwater or remote measuring
  • Uses alkaline or rechargeable batteries (built-in charger)


  • Statistics mode continually displays/updates average, standard deviation, min/max thickness and number of readings while measuring
  • HiLo alarm audibly and visibly alerts when measurements exceed user-specified limits
  • FAST mode – faster measurement speed for quick inspection
  • USB port for fast, simple connection to a PC and to supply continuous power. USB cable included
  • USB mass storage – stored readings and graphs can be accessed using universal PC/ Mac web browsers or file explorers. No software required
  • Every stored measurement is date and time stamped
  • Software updates via web keep your gage current
  • Connects to


Measuring principle: magnetic induction principle (Ferrous)
eddy-current principle (Non-Ferrous)
Surface Temp. Maximum 120 °F / 49 °C
Power 3 AAA batteries, Included
Dimensions 5″ x 2.6″ x 1″ (127 x 66 x 25.4 mm)
Weight 4.9 oz. (137 g) without batteries
Protection Class Meets or exceeds IP5X, Solvent, acid, oil, water & dust resistant
Warranty 2 Years
Min. Concave Radius 1 inch (2″ OD)
Standards Conforms to ISO 2178/2360/2808, PrEN ISO 19840, ASTM B499/D1186/ D1400/D7091/E376/G12, BS3900-C5, SSPC-PA2 and others
Probe Cable Length 3 ft (1 meter)
Nickel-Plating Nickel-plating with a phosphorus content of 8% or greater makes it a “non-magnetic” coating (typically Electroless Nickel Plating – EN) and it can be measured using a Ferrous probe.


Peso 0.5 kg
Dimensiones 20 × 20 × 15 cm
