Sinowon Horizontal Video Projector PH-3015
El Sinowon Horizontal Video Projector PH-3015 es un proyector de medición óptica de alta precisión diseñado para inspección dimensional. Permite ampliar y analizar perfiles de piezas con gran claridad en una pantalla horizontal, facilitando mediciones rápidas, comparaciones con plantillas y control de calidad en entornos industriales.
$0.00 USD
1 disponibles
1 disponibles
18
People watching this product now!
Payment Methods:
Descripción
Model:PH-3015
Code#:
#542-310
Accuracy:
≤3+L/200(um)
Warranty:
12 month
Delivery Time:
15-30days
Standard:
ISO10360
Certificate:
CE
Product Feature
◆ The lifting system adopts linear guide rail and precision screw drive, which makes the lift drive more comfortable and stable;
◆ With precision toothless rod and fast movement locking device, ensure return error is within 2um;
◆ High accuracy A optical scale and precision working stage, ensure machine accuracy is within 3+L/200 um;
◆ HD zoom lens and HD color digital camera, ensure clear image without distortion;
◆ With programmable surface 4-ring 8-division LED cold light and contour LED parallel illumination, it can control the brightness of the 4-ring 8-division independently;
◆ With powerful iMeasuring2.1 software system , to enhance the control quality;
◆ Optional imported contact probes and 3D measuring software, it can help upgrade the machine to be coordinate measuring machine;
◆ Optional FexQMS measurement data analysis and real-time monitor software, enhance process control, reduce material consumption;
Specification
Product Name |
Horizontal Video Projector |
Model |
PH-3015 |
Code# |
#542-310 |
Working Stage Travel |
355X125mm |
X/Y-axis Travel |
200X120mm |
Z axis |
110mm |
Measurement Accuracy* |
≤3+L/200um |
Resolution |
0.0005mm |
CCD |
HD Digital Camera |
Zoom Lens** |
HD 6.5X Detented Zoom Lens |
Optical Magnification:0.7X-4.5X; Video Magnification:23X~158X(21.5”monitor) |
|
Illuminating System (Software Control) |
Surface: Adjustable 4-ring 8-division 0~255-grade LED Cold Illumination |
Contour: LED Parallel illumination |
|
LED Laser navigation illumination |
|
Working Environment |
Temp：20℃±2℃，Temp Variation＜2℃/hr， Humidity：30％－80％RH，Vibration＜0.002g，< 15HZ |
Measurement Software |
iMeasuring 2.1 |
System |
Support XP, WIN7, WIN8，WIN10 32/64 Bit |
Power |
AC110V/60Hz; 220V/50Hz,600W |
Dimension |
1120 x 720 x1100mm |
Weight |
165kg |
