Fowler 52-550-005-0 Heavy-Duty Thickness Gages

Fowler’s Electronic Thickness Gages offers a variety of gages for your special gaging needs. All represent the state-of-the-art in performance and design and include the same features as the Ultra-Logic series

Compact and portable, the Electronic Thickness Gages are designed specifically for hand use. Ideal for conveniently measuring the thickness of a wide range of materials and small parts. Easy to hold in one hand. To operate simply press down the lifting lever. This raises the spindle, permitting easy insertion of work between the anvil and contact point. Releasing the lifting lever causes the spindle to contact the work being measured.

Fowler’s Dial Thickness Gages are light in weight, easy to handle and carry. These specially built gages are mounted in a hand contoured frame with a thumb release mechanism; has fast direct reading to .001″. Used to measure thickness of paper, cellophane, plastic film and metal plates. These are high quality precision instruments.

• Case finished in dull plated chrome.
• 52-550-005 and -020 measuring faces constructed in high grade tool steel; hardened, ground and lapped.
• 52-550-010 features ceramic anvils.
• Direct reading 0-100 (with revolution counter) on easy-to-read dial.
• Frame is hammertone baked enamel.
• Microfine graduations for .001″ or .01mm minimum reading.
• Spindle of hardened stainless steel.
• Features a thumb release mechanism.
• Includes case.
