Fowler 54-770-420-0 Premium Twin Scale Rockwell Type Hardness Tester
Featuring Bowers’ historic quality and high-accuracy the Ultima Bore Gaging System is the next generation of Bower’s famous Super-Bore line of bore gages and accessories.
$18,282.00 USD
3 disponibles
3 disponibles
11
People watching this product now!
Payment Methods:
Descripción
Features:
• Measures all Standard & Superficial Rockwell hardness values
• Simultaneous conversion to HV, HB and other HR scales
• Rugged fine casted frame allowing large dimension work pieces
• ASTM, ISO, JIS compliant
• ESELOAD™ unique motorised load application system, auto selection of main loads depending on HR scale (676 & 677 only)
• Superior depth measuring system through Heidenhain (Germany) transducer
• ESETOUCH™ advanced LCD touch screen & operator panel with user friendly menu operation in multiple languages
• High speed preload, loading and unloading procedure for ultra high efficiency
• ESELIFT™ (677 only) motorised elevating screw simplifies and speeds up test operation
• Automatic measurement procedure, load / dwell / unload (677 only)
• ESEMATIC™ fully automatic positioning and measuring procedure (positioning, preload, load, dwell, unload (676 and 677 models))
• Storage of 50 test programs and tester settings, allowing you to set up your tester in just seconds
• Alpha numerical data entry
• Continuous automatic “online’’ statistics, incl. average of readings etc. Technical Specifications
• Storage of 99 single hardness values
• Go / No Go mode
• Convex and concave measuring mode
• Calibration date expired (reminder)
• Service mode including electronic linearity calibration, tests counter, maintenance system
• Prints statistics to built-in printer or external printer
• Built-in high speed printer and USB2 data output with network capability
